R0909

电位器技术参数：
全阻值Total resistance:B5K±10%
阻型Resistance taper：A B C D 4种线性
残留阻值Residual Resistance：≦20Ω
杂音Sliding noise：DC10V ≦100mv
全回转角度Total Rotation angle：260°±10°
旋转力矩Rotational Torque：5～15gf
耐久次数值Number of cycles：100,000 cycles Min
工作温度范围Operating temperature range：-30℃to+85℃
