DS-271
检测开关技术参数：
额定电流Rating：1mA DC 5V
绝缘电阻Insulation resistance: 100MΩ min.100V DC
介电强度Dielectric strength: 250V AC for 1 min
接触电阻Contact resistance: 100m Ω max.
行程Travel: 0.30+0.20mm
操作力度Operating fore:≥30gf
寿命Life time:50,000 cycles
工作温度范围Operating temperature range：-30℃to+85℃
