    • TS-A009

    TS-A009

    轻触开关技术参数:
    工作温度范围Operating temperature range:-30℃to+85℃
    额定电流Rating:50mA.12V DC
    绝缘电阻Insulation resistance: 100MΩ min.100V DC
    介电强度Dielectric strength: 250V AC for 1 min
    接触电阻Contact resistance: 100m Ω max.
    行程Travel: 0.20±0.05mm
    操作力度Operating fore:180gf /250gf/300gf
    寿命Life time:≥100000cycles
